Pulsar C6

Description​

The PULSAR NANO ESP32 C6 is a compact and powerful development board featuring the ESP32-C6 microcontroller. Designed with compatibility in mind, it follows the Arduino Nano form factor and pin distribution, making it easy to integrate with existing shields and projects.

Key features include:

  • Wi-Fi 6, Bluetooth 5 (LE), Thread, and Matter support.
  • Built-in LiPo battery charging circuit.
  • MicroSD card socket for external storage.
  • QWIIC connector for seamless sensor and module integration.
  • Onboard WS2812-2020 Neopixel LED for visual feedback.
  • IEEE 802.15.4 support, enabling robust low-power wireless communication for Thread and Matter applications.

For more details, check out the product pages at:

Features​

  • Microcontroller:

    • ESP32-C6: RISC-V processor, Wi-Fi 6, Bluetooth 5 (LE), Thread, and Matter support, making it perfect for next-generation IoT applications and smart home automation.
    • IEEE 802.15.4 compliant, ensuring reliable Thread communication and full Matter compatibility for seamless integration into smart home ecosystems.

  • USB Connectivity:

    • USB Type-C interface for power and data.

  • Power Supply:

    • Integrated LiPo battery charging circuit.
    • Wide input voltage support with onboard regulation.

  • Storage:

    • MicroSD card slot for external storage.

  • I2C Connectivity:

    • QWIIC connector for easy expansion with sensors and peripherals.

  • Additional Features:

    • WS2812-2020 Neopixel LED for visual feedback.
    • Full compatibility with the Arduino Nano form factor and shields.

Applications​

The PULSAR NANO C6 is ideal for:

  • Internet of Things (IoT): Wi-Fi 6, Thread, and Bluetooth 5 enable robust connectivity.
  • Smart Home & Automation: Full Matter support ensures seamless interoperability with modern smart home ecosystems.
  • Low-Power Wireless Networks: IEEE 802.15.4 support makes it suitable for efficient, low-energy communication in Thread-based IoT applications.
  • Education & Prototyping: Arduino Nano compatibility ensures easy project integration.
  • Embedded Systems: Compact size with low-power operation for efficient solutions.
  • Wireless Networking: Designed for future-proof IoT applications with advanced communication protocols.

Getting Started​

The PULSAR NANO C6 supports:

  • Arduino IDE with ESP32-C6 board package.
  • MicroPython and with compatible IDEs like Thonny.

For setup and first projects, refer to the Getting Started Guide.

Schematic​

For detailed circuit design, refer to the Hardware Documentation and the full schematic available in the repository.

Development Resources​

ResourceLink
Arduino Package ESP32-C6 JSONESP32-C6 Package
MicroPython DocumentationMicroPython.org
PULSAR NANO C6 DocumentationPULSAR NANO C6 Documentation
Getting Started with PULSAR NANO C6PULSAR NANO C6 Guide
Thonny IDEThonny.org
Arduino IDEArduino IDE
Visual Studio CodeVisual Studio Code
ESP32-C6 DatasheetESP32-C6 Datasheet
